REGULATED GLOVE BOX

The regulated glove box is a modular and custom-made glove box designed for experiments and processes under gas or specific mixtures..

Thanks to our range of equipment developed by our design office, it can be transformed into a climate glove box with adjustable parameters in both directions in pressure regulation, temperature, humidity, oxygen … Our expertise has created a very flexible enclosure in which you can generate cold or heat the atmosphere as well as moistening or drying the atmosphere and control O2 or CO2 rates….

It is available in standard and custom sizes...

APPLICATIONS

picto-jacomex-recherche-laboratoire
picto-jacomex-industrie
picto-jacomex-nucleaire

0

DIMENSIONS

modele-boite-gants-g-box

ADVANTAGES
 Flexible and easily upgradable
 Standard and custom models
 Possible connection with other range of JACOMEX glove boxes
 Ideal for controlled atmospheres with automatic regulation of moisture (0-70%RH) and/or oxygen (<1%O2)
 Wide range of transfers systems
 3D design drawings



boite-gants-g-box

POSSIBLE APPLICATIONS...
 Configurable climatic chambers:
     - Moisture(% RH): drying and/or humidification
     - Temperature: heating and/or air-conditioning


 Development of Perovskite photovoltaic cels (PSC)
 Slow-oxygen reducing atmosphere against flammability or explosiveness (chemical substances, powders...)

TECHNICAL DATA
Tightness Class 1 according to ISO 10648-2 (oxygen method)
    Leak rate < 5.10E-4/h (0.05 Vol%/h)
Silicon-free gaskets (removable panels)
Chamber: stainless steel X2CrNi18-9 (AISI304L)
Front panel: polycarbonate - mineral laminated glass
Roof lighting (LED spotlights)
1 electrical feedthrough 230V + 2 ISO KF40 feedthroughs
Automatic pressure regulation
Compatible with all JACOMEX options and equipment



g-box-v2-glove-box
